| | Delivery
specification |
One of the most confusing part of purchasing a log home may be the contents of
the delivery packages. Like most of handcrafted companies, we supply our customers mainly
with the “Log Part” only, but it is also possible to order the “Weather Tight Shell” or
optional delivery package redacted to suite your needs. Upon request we provide the mounting
of our products on construction site.
The delivery package specification contains the packages available by our company.
The “log part” delivery package includes:
 |
 |
1. External and internal handcrafted log wall details and log gable ends: grooved, pivoted, marked and ready to be assembled.
1.1. Material: pine, massive
1.2. Profile: square timber, thickness 200 mm
1.3. Mitre joint: ‘Norwegian dovetail’
2. Log part load bearing construction
2.1. Log beams
2.2. Log purlins
2.3. Supportive post
3. Means for assembling
3.1. Wooden rods
3.2. Tenon boards
3.3. All necessary metallic parts
4. Additional accessories
4.1. Moisture barrier under the first row of logs
4.2. Insulation material to be used between the logs
|
The “weather tight shell” delivery package includes:
 |
|
1. Log part
1.1. External and internal handcrafted log wall details and log gable ends: grooved, pivoted, marked and ready to be assembled.
1.1.1. Material: pine, massive
1.1.2. Profile: square timber, thickness 200 mm
1.1.3. Mitre joint: ‘Norwegian dovetail’
1.2. Log part load bearing construction
1.2.1. Log beams
1.2.2. Log purlins
1.2.3. Supportive post
1.3. Means for assembling
1.3.1. Wooden rods
1.3.2. Tenon boards
1.3.3. All necessary metallic parts
1.4. Additional accessories
1.4.1. Moisture barrier under the first row of logs
1.4.2. Insulation material to be used between the logs
2. Ground floor
2.1. Floor skirting list 21*80
2.2. Floor boards 28*95
2.3. Floor beams 50*100/200 , cc=600
2.4. False inserted floor boards 22*100
2.5. Metallic parts
3. First floor
3.1. Floor skirting list
3.2. Floor boards 21*80
3.3. Floor beams 50*100/200, cc=600
3.4. Ceiling panelling 125*18
3.5. Ceiling skirting board
3.6. Metallic parts
4. Roof (insulation thickness 200mm)
4.1. Bitumen roll roofing
4.2. Full roof boarding RPL 20*85
4.3. Roof ventilation 50*50
4.4. Rafters 50*200
4.5. Boards between rafters 50*100
4.6. Eaves facial boards 20*140
4.7. Eaves boards
4.7.1. Eaves gable boards 20*140
4.7.2. Panelling for eaves (if invisible rafters)
4.8. Ceiling beams 50*200 (if roof space construction)
4.9. Ceiling panelling 18*125
4.10. Ceiling skirting lists
4.11. Metallic parts
5. Balcony and terrace
5.1. Boards 28*120/145, impregnated
5.2. Floor beams, 50*200, cc=600
5.3. Railing (if not log railing)
5.4. Metallic parts
6. Framed walls
6.1. External panelling (if external framed wall)
6.2. Frame 50*100, cc=600
6.3. Internal panelling 125*18
6.4. Metallic parts
7. Windows and doors set
7.1. Wooden outwards opening Danish type of windows, external doors and balcony doors.
7.2. Outside cover boards
8. Assembling
8.1. Assembling and installation of our delivery package
8.2. Installation of wind barrier, moisture insulation, insulation materials
|
Optional materials:
1. The material for insulation
2. Material for wind barrier
3. Material for moisture insulation
4. Inner stairs with one side railing
5. Sauna internal and ceiling panelling
6. Windows and doors inside cover boards
7. Garden furniture
Our delivery packages do not include foundation, roof covering, rainwater system, wind barrier, moisture insulation, insulation materials, coloring, electrical wires, water pipes, canalisation pipes, materials for wet room floors and walls and other materials that are not described above.
|
|
